Clamping and Locating Angle Bores
● These locators are widely used.
● Locating Tools vary in height due to different workpiece.
● It can be flexible moved through the slot to adjust the distance to workpiece
● It can be used to fix the shape of workpiece in all aspects depending on the cooperation of more than one locating tools.
● It can also be used as a 90° standard rule
Description
Clamping and Locating Angle Bores
- These locators are widely used.
- Locating Tools vary in height due to different workpiece.
- It can be flexible moved through the slot to adjust the distance to workpiece
- It can be used to fix the shape of workpiece in all aspects depending on the cooperation of more than one locating tools.
- It can also be used as a 90° standard rule
D28 System:
| Model |
Size(mm) |
Weight (Kg) |
| LAB281751751 |
175x50x175 Bore/Bore |
2.5 |
| LAB281751752 |
175x50x175 Oblong/Oblong |
1.8 |
| LAB281751753 |
175x50x175 Bore/ Oblong |
2.2 |
| LAB2817575 |
175x50x75 |
1.5 |
| LAB287575 |
75x50x75 |
1 |
| LAB28275175 |
175x50x275 |
3 |
D16 System:
| Model |
Size(mm) |
Weight (Kg) |
| LAB1690901 |
90x30x90 Bore/Bore |
0.28 |
| LAB1690902 |
90x30x90 Oblong/Oblong |
0.2 |
| LAB1690903 |
90x30x90 Bore/ Oblong |
0.24 |
| LAB169037 |
90x30x37.5 |
0.15 |
| LAB165040 |
50x30x40 |
0.13 |
| LAB1614090 |
140x30x90 |
0.32 |
